> WINGUARD
> Ecg Machine
> With Interpretation
> Three Channel
> Model ECG 32A II
> 14.4V 1200mAh
> 1 unit
* Lead
Standard 12 leads
* Input Circuit
Isolated input circuit;
Protection against defibrillation and pace making
* Data Acquisition: Simultaneously 12 lead acquisition
* Calibration Voltage: 1mV?5%
* Sampling Rate:1.25ms
* A/D Converter: 12 bit
* Filter: AC filter; EMG filter; DFT filter
* CMRR
> 60dB;
> 100dB ( with AC filter in use)
* Input Circuit Current
?0.1?A
* Input Impedance
>50M?
* Patient Leakage Current
< 100?A
* Time Constant
?3.2s
* Frequency Response
0.05 ~ 150Hz
* Noise Level
< 15?Vp-p
* Paper Speed
6.25, 12.5, 25, 50mm/s
* Sensitivity
2.5, 5, 10, 20mm/mV
* Polarizing Voltage
?300mV
* Baseline Control
Automatic baseline control
Automatic inhibition of baseline drift
Note:
* Do not directly contact together positive and negative poles of the battery. Otherwise, there will be the hazard of fire
* Do not place the battery near a fire. Otherwise, there will be the hazard of explosion
* Do not disassembly the battery without professional instructions.
* The battery shall be a hazard with care and not be dropped
